USB RS232 QR Code Engine 1280x1080 Resolution Electronic Material

Ask Lasest Price
Brand Name :	HST
Certification :	Rohs，Aiming (red laser) :EN/IEC 60825-1:2007 (class 2)
Price :	2usd
Payment Terms :	L/C, T/T
Supply Ability :	10,000 pcs/day
Delivery Time :	7-10 days
Model Number :	T20

Add to Cart

Product Details
Company Profile

USB RS232 QR Code Engine 1280x1080 Resolution Electronic Material

Code Engine 1280*1080 Resolution Electronic Material QR Code Scanning Engine

Description:

The Code Engine 1280*1080 resolution electronic material QR code scanning engine is a high-resolution electronic component designed specifically for QR code scanning services. It features a 12801080 resolution image processing capability, providing clearer and more accurate scanning results.

The Code Engine 1280*1080 resolution electronic material QR code scanning engine has several features. Firstly, it has a high-resolution image sensor that captures more details and delivers clearer images. Secondly, it supports fast image processing and decoding algorithms, enabling faster and more efficient scanning. Thirdly, it possesses excellent optical performance and autofocus functionality, adapting to QR code scanning at different distances and angles. Fourthly, it typically has stable connectivity interfaces such as USB or wireless connections, facilitating integration with other devices.

The Code Engine 1280*1080 resolution electronic material QR code scanning engine is widely used in various scenarios that require high-resolution scanning. It can be applied in e-commerce, logistics tracking, ticket validation, and production process control, among other fields. By utilizing this high-resolution scanning engine, users can obtain more precise and reliable QR code scanning results, thereby improving work efficiency and data accuracy.

Specification:

Image Senor	Global shutter
Resolution	1280*1080
Illumination	Red LED
Aim	Laser
Field of View	H:40.9°；V:31.2°
Reading Angle	Tilt: ±70° rotation 360° deflection ±55°
Readable Contrast	15%
Support Code System
1D	Codabar,Code11,Code128,ISBT128,Code32,Code39,TLC39,Code93/93i, BC412,UK Plesey,Anker Plesey,EAN-13,EAN-8,GS1,MSI,Telepen, Pharma,PatchCode,UPC-A,UPC-E,2 fo 5 (ChinaPost,Interleaved 2 of 5,Matrix 2 of 5,NEC 2 of 5,Straight 2 of 5 iATA,Straight 2 of 5 Industrial)
2D	AztecCode,HanXin,DataMatrix,MaxiCode,QR,Micro QR,rMQR, Dot Code,GridMatrix,CodablockA,CodablockF,PDF417,Micro PDF417
Postal	KoreaPost,ChinaPost,AustraliaPostal,Royal INFOMAIL,Japan Postal,KIX,PLANETCODE,POSTNET,BritainPostal,UPU,USPS 4STATE
Depth of Field(100MM)
Coding System	Effective Reading Distance (mm)	Depth of Field (mm)
5mil code39	60-150	90
13mil EAN13	50-325	275
10mil DM	40-225	185
15mil DM	35-295	260
20mil Code	135-415	280

Details:
